Elco Lighting E616C1227W 6 Inches LED Light Engine with Adjustable Baffle Trim, 2700K - White Finish

The perfect lighting solution for high-end residential and light commercial projects.

Features:

High efficacy LED module.
Triac/ELV/0-10V dimming.
Life span of 50,000 hours L70.
USA designed and assembled.
Limited 5 year warranty.
2 at the end of the item number denotes Generation 2.
Please note Gen 2 and Gen 1 are not cross compatible

Specifications:

Wattage 12.88W
Lumens 1250 lm
Color Temp. 2700K
Lamp Type LED
Beam Angle 60°
CRI 93+
Damp Location Listed

Technical Details:

Optics: Frosted polycarbonate module lens diffuses light evenly throughout while reducing glare with LED technology.

Trim Construction: Reflector is two piece trim for maximum color versatility. Design allows for minimal glare and a strong glare cut-off. Trim is constructed of metal for lasting durability.

Installation: Must be installed on a Cedar System frame with compatible lumen rating. Frames are available for New Construction and Remodel as IC or non-IC.

LED Technology:
Extremely accurate Color Rendering Index of 93+.
Efficacy of 97 lumens per watt.
Lumen Maintaince of 50,000 hours L70 Life based on LM80 standardized test results.
Superior Thermal Management by utilizing ELCO Red heat sink.
Instant On to Full Brightness technology.
No LED pixelation.

Listings:
UL Listed for Wet Location.
RoHS Compliant.
California Title 24 (JA8-2016-E).
