Description
Technical Specifications
- 120V/277V AC Dual Voltage Operation
- Light Head Wattage: 2.4W Per Head
- Sign Wattage: 3.5W
- Input Power: 2.90-3.79W
- AC Charging Current: 32mA
- Fully Automatic Solid-State, Two Rate Charger Initiates Battery Charging to Recharge a Discharged Battery in 24 Hours
- Built-in 3.6V 1200mAh Ni-Mh Battery for Minimum 90 Minutes Emergency Operation
- Injection-Molded Thermoplastic ABS Housing and Polycarbonate Cover, UL 94V-0 Flame Rating
- Injection-Molded Thermoplastic ABS Housing and Polycarbonate Cover, UL 94V-0 Flame Rating
- Red Green Lenses are Included. The Default is Red
- To Change Color of the Sign Change the Lens Flip the Color Switch Inside
- Single or Double Face (Universal)
- Letters 6" Height with 3/4" Stroke
- Operating Temperature: 32ºF~104ºF
- Maximum 24 Hours for Full Recharge Time
- Universal J-Box Mounting Pattern
- Injection-Molded Thermoplastic ABS Housing and Polycarbonate Cover, UL 94V-0 Flame Rating
- Innovative, Easy Installation in Minutes
- IP20, Indoor Use Only
- Color Temperature: 6132K
- Total Lumens: 8 (AC)/ 272
- Options at checkout: Remote Capable (designed with a high capacity battery backup system that is capable of powering one or more additional external emergency light remote heads for the 90 minute minimum emergency run time)
Applications
- Ideal for every exit door, at the intersection of corridors, at exit stairways or ramps and such other locations
