Product details

Description

Technical Specs

  • ADC12 Aluminum Heat Sink, Outdoor Powder Coating
  • Connect One End or Both Ends (Dual Function)
  • Multi Power CCT (Switches are inside fixture)
  • Prismatic Borosilicate Glass Lens
  • Voltage: 120-277V AC 60Hz
  • Four 1/2€šš½ hubs: 1 top. 1 on each side, 1 rear
  • Chip: Lumileds LEDs
  • Dimming: 0-10V
  • Efficacy: 130 LPW
  • CRI 70
  • Power Factor: 0.9
  • Operating Temp: -40F to 104F
  • Lifespan: 70,000 hours
  • 7-year warranty
  • IP Rating: IP65, Wet Locations
  • Color Temperatures: 3000K/4000K/5000K/5700K

Applications

  • Ideal for general site lighting, alleys, loading docks, doorway, pathway and parking areas.
  • Replace existing HID wall packs
  • Great for use with photocell
