Westgate ULR-IN-PIDR-48W LED Indoor Electronic Ribbon Light Plug-In Drivers, 48W

• Input voltage: 100~240VAC, 50/60Hz
• AC Input Current: Max 0.5A
• Output power: 48W
• Output DC Voltage: 24VDC
• Min Load: 0.00A
• Rated Load: 2A
• Line Regulation: ± 1%
• Load Regulation: ± 5%
• Efficiency: 82% Min
• Turn on delay time: 3Sec Max. at 115VAC Max Load
• Rise time: 40mS Min. at 115VAC Max Load
• Hold up time: 5mS Min. at 115VAC Max Load
• Male 24V connector included
• Operating Temperature: 32F to 104F
• Protection Function: Short Circuit Test, Over current protection, Over Voltage Protection
• Relative Humidity: 5% to 90% RH, 72Hrs, Full Load , Normal operating.
• Ripple and Noise: 240mV p-p
• EN55022
• AC power cord can be cut for hardwiring. Ensure proper installation according to local electrical codes and standards.
• DIELECTRIC STRENGTH Hi-Pot: Primary to secondary: 3000Vac10mA/3S for type test.
• Insulation resistance: Primary to secondary:10MΩ min at 500V DC
