Description
Technical Specs
- Voltage: 120-277V; 60Hz / 480V; 60Hz
- Power Factor: 0.95
- Wattage: 15W/20W/30W/50W/80W/100W/150W/200W
- Efficacy: 140LM/W
- Die-cast Aluminum with Powder Coat Finish (Light Grey)
- Cord Type: 40" SJTW 18/3 AWG Cable
- With 2-15/16" Diameter Pole Entry with Adapter Bracket Inside for Smaller Pole Diameters
- Maximum Ambient Temperature: 104F
- IP Rating: IP65, Suitable for Wet Location
- 7-Year Warranty
- MP: Multi-Power Switch is Located on the Back of the Fixture
- Lens Type: Optical TYPE III Lens, High Light Transmittance PC, Anti-UV and Flame Resistant
- Dimming: 0-10 Dimming
- Driver Located in Isolated Compartment for Improved Thermal Management
- Total Lumens: 7250LM/14500LM/21000LM/28000LM/14000LM/28000LM
- Color Temperatures: 3000K/5000K
- Color Rendering Index: CRI ‚¬° 70
- Rated Life: 70,000 hrs
Applications
- Ideal for general site lighting, streets, roadway, alleys, loading docks, doorways, pathways and parking areas
