Product details

Description

Sizes

  • 3" 6W 400 Lumens
  • 4" 9W 630 Lumens
  • 6" 15W 1125 Lumens
  • 8" 18W 1350 Lumens
  • 10" 20W 1500 Lumens
  • 12" 24W 1800 Lumens

Technical Specs

  •  Suitable for Wet Locations
  • Voltage: 120V
  •  Output Voltage: 36VDC
  •  Power Factor: 0.90
  • Efficacy: 70 LPW
  • Total Harmonic Distortion:15 %
  • 1/4"Thick
  • Up to 9 AWG18 Wires
  • Die-cast Aluminum with White Powder Coat Finish
  • Pot Light Housing is Not Required even for Insulated Ceiling
  •  Junction Box 1" Thick Included with Fixture
  • Type Crated: Approved for Direct Contact with Insulation
  •  Maximum Ambient Temperature: -40F to 104F
  • Dimming: Dimmable Down to 10% Using a Standard TRIAC LED Dimmer
  •  Lens: 0.125" White Translucent Acrylic
  •  Can Rotate after Installation to Align
  • LED: Seoul DOB (Driver on Board) Technology
  •  Optics: White Translucent Acrylic
  • 5CCT Color Temperatures: 2700K/3000K/3500K/4000K/5000K
  • Multi CCT (Selectable Switch on the Back of the Driver)
  •  Color Rendering Index: CRI 80
  •  Beam Angle: 100-110
  •  Rated Life: 50,000 Hours

Applications

  • LED recessed trims have been designed to be a flexible lighting solution for new construction applications, ideal for closets, storage areas, attics, corridors, or general lighting solutions for residential and commercial applications
