Westgate RSL6-G2-MCT5-ORB 6" RSL G2 Second Generation Slim Wafer Light - Oil-Rubbed Bronze
Westgate RSL6-G2-MCT5-ORB 6" RSL G2 Second Generation Slim Wafer Light - Oil-Rubbed Bronze
Westgate RSL6-G2-MCT5-ORB 6" RSL G2 Second Generation Slim Wafer Light - Oil-Rubbed Bronze
  • Brand: Westgate
  • Part #: RSL6-G2-MCT5-ORB

Westgate RSL6-G2-MCT5-ORB 6" RSL G2 Second Generation Slim Wafer Light - Oil-Rubbed Bronze

Sale price$18.74Regular price $18.78

Pickup available at Sonic Distribution Center

Usually ready in 24 hours

Pairs well with

Fast & Reliable Shipping

Orders processed in 1–2 business days.

Hassle-Free Returns

30-day returns on eligible items. Read Terms

Knowledgeable Support

Get expert help via chat, email or phone.

Top-Rated Store

Trusted by 20,000+ customers. Read Reviews

Product Details

Description

Technical Specs

  • :: Voltage: 120V AC
  • :: Output Voltage: 36VDC
  • :: Power Factor: 0.90
  • :: Wattage: 12W
  • :: Efficacy: 83 LPW
  • :: Total Harmonic Distortion: š¬°15 %
  • :: 1/4½Thick
  • :: Up to 9 AWG18 Wires
  • :: Die-Cast Aluminum With Powder Coat Finish
  • :: Pot Light Housing Is Not Required Even For Insulated Ceiling
  • :: Junction box 1½ Thick Included With Fixture
  • :: TypeI Crated: Approved For Direct Contact With Insulation
  • :: Maximum Ambient Temperature: -40°F to 104°F
  • :: Damp Location
  • :: Dimming: Dimmable Down to 10% Using a Standard TRIAC LED Dimmer
  • :: Lens: 0.125½ White Translucent Acrylic
  • :: Can Rotate After Installation to Align
  • :: LED: Seoul DOB (Driver On Board) Technology
  • :: Optics: White Translucent Acrylic
  • :: Total Lumens: 1000LM
  • :: Color Temperatures: 2700K/3000K/3500K/4000K/5000K
  • :: Multi CCT (Selectable Switch On The Back of The Driver )
  • :: Color Rendering Index: CRI š¬° 80
  • :: Beam Angle: 100°-110°
  • :: Rated life: 50,000 hrs

  Applications

  • :: LED recessed trims have been designed to be a flexible lighting solution for new construction applications, Ideal for closets, storage areas, attics, corridors, or general lighting solutions for residential and commercial applications

Download PDF File

Specification

Installation Instruction
