Details of the Westgate RDG2TL-MCT5 2" Round Gimbal Trimless Recessed Downlight, 6W, 5CCT Selectable, 400 Lumens, 90 CRI - White Finish

The Westgate RDG2TL-MCT5 is a 2-inch round gimbal trimless recessed downlight designed for precise directional lighting in a compact architectural form. Its 6W COB LED produces 400 lumens at 66 lm/W, while the 5CCT selectable design offers 2700K, 3000K, 3500K, 4000K, and 5000K options. The 90 CRI light source and deep-regress optical design provide quality illumination with a clean, discreet ceiling appearance.

The adjustable gimbal provides 360° rotation and 30° tilt, allowing light to be directed toward artwork, displays, architectural features, or other focal areas. This white trimless downlight features TRIAC/ELV dimming, a Class 2 isolated remote driver, polycarbonate lens, and die-cast aluminum heatsink. Its canless mud-in installation, compact 2-inch aperture, and 2-13/16-inch round ceiling cutout make it suitable for both residential and commercial accent lighting applications.

Key Features

• 2-inch round gimbal trimless recessed downlight
• 6W COB LED delivers 400 lumens
• 66 lm/W efficacy
• 5CCT selectable: 2700K / 3000K / 3500K / 4000K / 5000K
• 90 CRI for enhanced color rendering
• Gimbal adjustable with 360° rotation and 30° tilt
• Deep-regress optical design
• White finish for a clean architectural appearance
• Polycarbonate lens
• Die-cast aluminum heatsink
• TRIAC / ELV dimmable
• Class 2 isolated low-voltage remote driver included
• CCT selection switch located on the driver box
• Trimless mud-in, canless recessed installation
• Round mud-in plate included
• Suitable for directing light toward artwork, displays, and architectural features
• ETL Listed

Technical Specifications

• Brand: Westgate
• Model: RDG2TL-MCT5
• Product Type: Round Gimbal Trimless Recessed Downlight
• Input Voltage: 120 VAC, 60 Hz
• Dimension: w-2.28 in x d-3.72 in x h-2.5 in
• Wattage: 6W
• Delivered Lumens: 400 lm
• Efficacy: 66 LM/W
• CCT: 2700K / 3000K / 3500K / 4000K / 5000K Selectable
• CRI: 90
• Dimming: TRIAC / ELV
• Power Factor: >0.9
• Total Harmonic Distortion: <25%
• Light Source: COB LED
• Optical Design: Deep Regress
• Lens: Polycarbonate
• Aperture: Round
• Aiming: 360° Rotation / 30° Tilt
• Driver: Class 2 Isolated Low-Voltage Remote Driver Box
• Wiring: FT4-Rated Cable with Male/Female Quick Connector
• Minimum Supply Conductor Temperature: 194°F
• Housing: Die-Cast Aluminum Heatsink
• Finish: White
• Installation: Trimless Mud-In, Canless Recessed
• Certification: ETL Listed
