Product details

Description

Technical Specs

  • Voltage: 120~277V AC/50~60 Hz
  • Wattage: 15W
  • Color Temperature: 5000K
  • Power Factor: 0.9
  • Efficacy: 130 LPW
  • Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze and White Finish)
  • Solid State Lighting Technology for Long Life, No Maintenance Needed and High-Efficiency
  • High Conductive Aluminum LED Board
  • 90° Adjustable 1/2" Knuckle Mount
  • IP Rating: IP65
  • Operating Temperature: -40°F to 104°F
  • Suitable for Wet Locations
  • Dimming: 0~10V Dimmable
  • Optic Lens Type: III
  • Cord Type: 13#18 AWG Stranded Wires
  • Total Lumens: 1950LM
  • Color Rendering Index: 82
  • Beam Angle: 120°X 90°

  Applications

  • Ideal for general site lighting, alleys, loading docks, doorway, pathway, and parking areas.
  • Replace existing HID flood lights/wall packs.

Download PDF File

Specification

Installation Instructions

Catalog Page
