Westgate LF4MAX - MD - 20 - 50W - MCTPB - TR - P Maximum - Feature Round - Back Flood Light with U Bracket, 20W/30W/50W, 30K/40K/50K - Bronze - Sonic Electric
  • Brand: Westgate
  • Product No: LF4MAX-MD-20-50W-MCTPB-TR-P

Westgate LF4MAX-MD-20-50W-MCTPB-TR-P Maximum-Feature Round-Back Flood Light with U Bracket, 20W/30W/50W, 30K/40K/50K - Bronze

$109.74

Pickup available at Sonic Distribution Center

Usually ready in 24 hours

Pairs well with

Fast & Reliable Shipping

Orders processed in 1–2 business days.

Hassle-Free Returns

30-day returns on eligible items. Read Terms

Knowledgeable Support

Get expert help via chat, email or phone.

Top-Rated Store

Trusted by 20,000+ customers. Read Reviews

Product Details

Description

Technical Specs

  • Voltage: 120~277VAC/50~60 Hz
  • Wattage: 20W/30W/50W
  • Power Factor: 0.9
  • Efficacy: 140LPW
  • Housing: Die-cast Aluminum Housing with Powder Coat Finish (Dark Bronze)
  • 270 Adjustable Yoke Mount
  • Photocell Included (With Disconnect Switch)
  • 6KV Lightning Surge Protection
  • Cord Type: 6ž¢ SJTW 18/3 AWG cable
  • Operating Temperature: -40F to 104F
  • Suitable for Wet Locations
  • Effective projected areas (EPAž¢s) are: Front = 0.38 square feet Side = 0.30 square feet Face = 1.05 square feet
  • IP Rating: IP65
  • 7-Year Warranty
  • Dimming: 0~10V Dimmable
  • Multi-CCT Multi-Power - The Switches are on the Bottom of the Fixture
  • Total Lumens: 7000LM
  • Color Temperature: 3000K/4000K/5000K
  • Color Rendering Index: %70
  • Adjustable Beam Angle: 135x125/120x120/90x90
  • 70,000 Hours Rated Life

Applications

  • Ideal for general site lighting, alleys, loading docks, doorway, pathway and parking areas.
  • Replace existing HID flood lights/ wall packs

Download PDF File
