Description
Technical Specs
- ADC12 Aluminum Alloy- Outdoor powder coated
- 3/4" NPT threaded hubon the top allows stem mounting
- Multi-power selectable switch is on the side of the fixture
- Programmable Bi-level Motion Sensor Emergency Backup Options
- Optical Lens: High Transmittance PC, Anti-UV Fire Resistant
- LED: Lumileds LEDs
- Lumens: 21000LM Max
- Wattage: 80W/100W/120W/150W
- Voltage: 120~277V AC, 50/60Hz
- Efficacy: 140LM/W
- Beam Angle: 100 x 100
- Power Factor: 0.95
- Operating Temp: -40F to 104F
- Color Rendering Index: CRI 70
- Color Temp: 5000K
- Lifespan: 70,000 hours
- 7-year warranty
- IP Rating: IP65, Wet Locations
Applications
- Ideal for airports, auto dealerships, corporate offices, education, government, healthcare, industrial warehouses, municipal parking, gas stations, convinient stores, recreation and public venues, restaurants, hospitality, retail and grocery stores.
Download PDF File
Catalog Page
Specification
Installation Instructions
