Westgate DAB-B20-50-100W-MCTP-SR Designer Area Bell Light System - Black

WestgateSKU: DAB-B20-50-100W-MCTP-SR

Price:
Sale price$361.74

Shipping calculated at checkout

Stock:
In stock

Pickup available at Sonic Electric

Usually ready in 24 hours

Description

Technical Specs

  • Voltage: 100-277V AC 50/60Hz
  • Wattage: 50W/80W/100W/150W
  • Power Factor: 0.9
  • THD20%
  • Efficacy: 130LM/W
  • AL1060 Aluminum Housing, Outdoor Powder Coating
  • Twist-Lock Zhaga Socket Pre-Installed. See Motion
  • Sensor Accessories.
  • 6€™ SJTW 18,3 AWG Power Cable
  • 6€™ SJTW Dimming Cable
  • Aluminum LED board: High Conductive, Waterproof, Aging Resistance, Salt resistance
  • Programmable Bi-Level Motion Sensor & Emergency Backup Options
  • Operating Temperature: -40F~104F
  • IP Rating: IP66, Suitable for Wet Locations
  • 7-Year Warranty
  • Multi CCT and Power: Selectable Switch Inside Of The Fixture
  • Dimmable: 0~10V Dimming
  • Lens: High Light Transmittance PC, anti-UV and Fire Resistant
  • LED: Lumileds 2835
  • Total Lumens: 13000LM-19500LM Max.
  • Color Temperature: 3000K/4000K/5000K
  • Color Rendering Index: >70
  • Beam Angle: Type V (150 X 150)
  • Lifespan: 70000 Hrs.

Applications

  • Ideal for Gardens, Amusement Parks, Residential Quarters, Industrial Parks, and Pedestrian Streets.

Download PDF File

Specification

Installation Instructions
