Technical Specs
- Die-cast aluminum housing
- Traffic rated: not likely to get damaged from activity around the light, including lawn care, as well as foot and auto traffic
- Solid state lighting technology for long life, no maintenance needed and high-efficiency
- 4" PVC sleeve with three 1/2-inch KO. 2 on sides, 1 on bottom.
- High conductive aluminum LED board
- LED: Built in integrated LED
- Optical PC Flat Lens
- Lumens: 320LM, 720 LM
- Wattage: 3W or 7W
- Voltage: 12-24V AC/DC
- Input Current: 1A Max
- Efficacy: 106LPW
- Beam Angle: 30
- Power Factor: 0.9
- Operating Temperature: -4F ~ 104F
- Color Rendering Index: CRI 90
- Color Temp: 3000K
- Lifespan: 50,000 hours
- 1-year warranty
- IP Rating: IP67, Wet Location
Download PDF File
Specification
Installation Instructions
