Specifications

• Manufacturer: Square D / Schneider Electric

• Part Number: FA34040

• Product Type: Molded Case Circuit Breaker

• Family: I-Line

• Series / Type: FA

• Frame: F-Frame

• Amperage: 40A

• Number of Poles: 3-Pole

• Phase: 3-Phase

• Voltage Rating: 480VAC

• Interrupting Rating: 18kA at 480VAC

• Interrupting Rating at 240V: 25kA

• DC Rating: 250VDC

• Interrupting Rating at 250VDC: 10kA

• Trip Type: Thermal-Magnetic

• Trip Functions: Long-Time / Instantaneous (LI)

• Mounting Type: I-Line Plug-In / Plug-On

• Terminal Type: Load-Side Lugs

• Wire Range: #14–1/0 AWG Copper / #12–1/0 AWG Aluminum

• Operating Temperature: 40°C

• Dimensions: Approximately 6.4" H × 4.5" W × 4.13" D

• Certifications: UL / CSA

• HACR Rated: Yes

• Condition: New

• Manufacturer Status: Discontinued

• UPC: 785901422686

• GTIN: 00785901422686

• Anticipated Product Weight: Approximately 9 lbs.

Product Description

The Square D FA34040 is a 40-Amp, 3-pole, 480V I-Line molded case circuit breaker designed for commercial and industrial power distribution applications.

Part of Square D's FA Series F-Frame, the FA34040 features an I-Line plug-in mounting configuration with thermal-magnetic overcurrent protection and long-time / instantaneous trip functions.

The breaker provides an interrupting rating of 18,000 AIC at 480VAC and 25,000 AIC at 240VAC. It is rated for 3-phase applications and includes load-side lug terminals accepting copper and aluminum conductors.

The FA34040 is a discontinued Square D circuit breaker primarily used as an exact replacement in compatible Square D I-Line panelboards and switchboards.

Key Features

• 40 Amp

• 3-Pole

• 3-Phase

• 480VAC

• 18,000 AIC at 480VAC

• 25,000 AIC at 240VAC

• Square D I-Line

• FA Series / F-Frame

• I-Line plug-in mounting

• Thermal-magnetic protection

• Long-time and instantaneous trip functions

• Load-side lug terminals

• Copper and aluminum conductor compatibility

• UL / CSA certified

• HACR rated

• New condition

• Discontinued legacy Square D breaker

Important Compatibility Information

The FA34040 is an I-Line style breaker. It should not be confused with similarly numbered Square D F-frame breakers that use different mounting configurations, including the FAL34040.

Before ordering, verify the FA34040 part number, 40A rating, 3-pole configuration, 480V rating, F-Frame construction, I-Line mounting configuration, interrupting rating, and physical dimensions against your existing breaker and electrical equipment.

Do not select a replacement breaker based solely on amperage and pole count.
