Details of the Nora Lighting NX-815-LEDRMA Recessed Adjustable LED Edge-Lit Exit Sign, Battery Backup, 6" Red Letters, Single Face, Mirrored Acrylic, Aluminum Housing

The Nora Lighting NX-815-LEDRMA Recessed Adjustable LED Edge-Lit Exit Sign combines premium architectural styling with dependable emergency egress performance. Designed for commercial, institutional, and high-end interior environments, this recessed LED exit sign features a mirrored acrylic face panel, natural aluminum housing, and bright 6-inch red EXIT lettering that provides exceptional visibility while maintaining a sleek, modern appearance. Its recessed design conceals the wiring compartment within a galvanized steel housing, making it ideal for office lobbies, hotels, museums, galleries, healthcare facilities, educational buildings, and upscale retail spaces.

Engineered with energy-efficient LED technology, the NX-815-LEDRMA delivers long-lasting illumination with minimal power consumption. The adjustable acrylic face can be positioned from 0° to 90°, allowing flexible installation on walls, ceilings, or sloped surfaces while maintaining optimal visibility. The mirrored acrylic panel features rounded, finished edges that enhance the fixture's architectural appeal and create a refined edge-lit effect.

For emergency preparedness, this model includes a replaceable Ni-Cad battery backup that provides a minimum of 90 minutes of illumination during power outages. Dual-voltage 120/277V input compatibility, integrated test button, charge indicator, and advanced surge and short-circuit protection ensure reliable operation and code compliance in demanding commercial applications. UL Listing and compliance with NEC, NFPA, and California Title 20 standards provide added confidence for professional installations.

Key Features

• Recessed adjustable LED edge-lit exit sign
• Bright 6-inch red EXIT lettering for high visibility
• Single-face mirrored acrylic panel design
• Natural aluminum housing for a modern architectural appearance
• Adjustable face rotates from 0° to 90° for wall, ceiling, or sloped installations
• Energy-efficient long-life LED light source
• Replaceable Ni-Cad battery backup included
• Provides 90 minutes of emergency illumination during power outages
• Dual-voltage 120/277V input compatibility
• Concealed wiring compartment for a clean recessed installation
• Rounded acrylic panel edges for enhanced aesthetics
• High-charge/ready indicator light with test button
• Isolated surge and short-circuit protection
• Deep-discharge battery protection circuitry
• Adhesive-mounted directional chevrons included
• Suitable for offices, hotels, hospitals, schools, museums, galleries, and retail environments
• UL Listed and compliant with NEC, NFPA, and California Title 20 standards
• Long-life LED system rated for approximately 25 years of operation

Specifications

• Brand: Nora Lighting
• Model: NX-815-LEDRMA
• Product Type: Recessed LED Edge-Lit Exit Sign
• Series: NX-815 LED
• Operation: Battery Backup
• Face Type: Single Face
• Panel Material: Mirrored Acrylic
• Housing Finish: Natural Aluminum
• Letter Color: Red
• Letter Height: 6 Inches
• Light Source: LED
• Input Voltage: 120/277V Dual Voltage
• Power Consumption: 3W Normal Operation / 5W Emergency Operation
• Battery Type: Replaceable Ni-Cad
• Emergency Runtime: 90 Minutes
• Mounting Type: Recessed Wall or Ceiling Mount
• Face Adjustment: 0° to 90°
• Housing Construction: Galvanized Steel with Die-Cast Cover Plate
• Testing Features: Test Button and Charge Indicator
• Protection: Surge, Short-Circuit, and Deep-Discharge Protection
• Listings: UL Listed
• Compliance: NEC, NFPA, State & Municipal Codes, California Title 20
• Warranty: 5-Year Limited Warranty
