Details of the Nora Lighting NX-815-LEDRCA Recessed Adjustable LED Edge-Lit Exit Sign, Battery Backup, 6" Red Letters, Single Face, Clear Acrylic, Aluminum Housing

The Nora Lighting NX-815-LEDRCA Recessed Adjustable LED Edge-Lit Exit Sign is a premium architectural emergency signage solution that combines modern aesthetics with dependable life-safety performance. Featuring a crystal-clear acrylic panel, bright 6-inch red EXIT lettering, and a sleek natural aluminum housing, this recessed exit sign is designed to blend seamlessly into upscale commercial interiors while maintaining exceptional visibility and code compliance. It is ideal for office buildings, hotels, museums, galleries, educational facilities, healthcare environments, and retail spaces.

Engineered with advanced edge-lit LED technology, the NX-815-LEDRCA provides bright, uniform illumination while consuming minimal energy. The adjustable acrylic face can be positioned from 0° to 90°, allowing installation on walls, ceilings, or sloped surfaces for maximum flexibility. The recessed design conceals the wiring compartment within a galvanized steel housing, creating a clean, low-profile appearance that complements modern architectural spaces.

For reliable emergency operation, this model includes a replaceable Ni-Cad battery backup that provides a minimum of 90 minutes of illumination during power failures. Dual-voltage 120/277V input compatibility, integrated test button, charge indicator, and surge protection circuitry ensure dependable performance and simplified maintenance. The fixture is UL Listed and complies with NEC, NFPA, and California Title 20 energy-efficiency requirements, making it suitable for a wide range of commercial applications.

Key Features

• Recessed adjustable LED edge-lit exit sign
• Bright 6-inch red EXIT lettering for clear visibility
• Single-face clear acrylic panel design
• Natural aluminum housing for a modern architectural appearance
• Adjustable face rotates from 0° to 90° for wall, ceiling, or sloped installations
• Energy-efficient long-life LED illumination
• Replaceable Ni-Cad battery backup included
• Provides 90 minutes of emergency operation during power outages
• Dual-voltage 120/277V input compatibility
• Recessed galvanized steel housing conceals wiring and components
• Rounded acrylic panel edges for a refined appearance
• High-charge/ready indicator light with test button
• Isolated surge and short-circuit protection
• Deep-discharge battery protection circuitry
• Includes adhesive-mounted directional chevrons
• Ideal for offices, hotels, museums, galleries, schools, healthcare facilities, and retail environments
• UL Listed and compliant with NEC, NFPA, and California Title 20 standards
• Long-life LED system rated for approximately 25 years of operation

Specifications

• Brand: Nora Lighting
• Model: NX-815-LEDRCA
• Product Type: Recessed LED Edge-Lit Exit Sign
• Series: NX-815 LED
• Operation: Battery Backup
• Face Type: Single Face
• Panel Material: Clear Acrylic
• Housing Finish: Natural Aluminum
• Letter Color: Red
• Letter Height: 6 Inches
• Light Source: LED
• Input Voltage: 120/277V Dual Voltage
• Power Consumption: 3.8W Normal Operation
• Battery Type: Replaceable Ni-Cad
• Emergency Runtime: 90 Minutes
• Face Adjustment: 0° to 90°
• Mounting Type: Recessed Wall or Ceiling Mount
• Housing Construction: Galvanized Steel with Die-Cast Cover Plate
• Testing Features: Test Button and Charge Indicator
• Protection: Surge, Short-Circuit, Brown-Out, and Deep-Discharge Protection
• Listings: UL Listed
• Compliance: NEC, NFPA, State & Municipal Codes, California Title 20
• Warranty: 5-Year Limited Warranty
