Envision S-CM-PIR-LV-SL Ceiling Mounted Sensor x SILVAIR Enabled - White

The Ceiling Mounted Sensor x SILVAIR Enabled offers precise 360° detection with PIR motion and daylight sensing for optimal energy efficiency. Operating at 12-24V DC with 50mA input, it features a snap-on ceiling design, sleek white finish, and IP20 dry location rating. With a 12-foot maximum mounting height and a 100-foot Bluetooth range (line of sight), it supports up to 3,000 devices per zone, making it perfect for indoor spaces requiring reliable, efficient lighting control.

Specifications:

• Brand: EnvisionLED

• SKU: S-CM-PIR-LV-SL

• UPC: 810143715972

• Input Voltage: 12-24V DC | 50mA

• Operating Temperature: -4-104F°

• Finish: White

• 360° detection

• Max Bluetooth Range: 100’ line of sight
   - Highly dependent on surrounding environment
   - Bluetooth test recommended for range accuracy

• IP Rating: IP20 Dry Location

• Snap-On: snap on ceiling design

• Max Mounting Height: 12ft

• Connect up to 3,000 devices on a zone

• PIR motion sensor: Ideal for indoor environments with clear lines of sight to the area of interest. Detects warm objects, good for high vibration, areas of metal.

• Daylight Sensor: controls power consumption of the fixtures based on sunlight levels
