Emcod 10W 3-42VDC Constant Current, Universal Dimming, Multi-Current with DPI Adjustment

EmcodSKU: ECC-010-UD

Price:
Sale price$48.00

Shipping calculated at checkout

Stock:
In stock

Description

ECC-UD - EMCOD Constant Current, Universal Dimming, Multi- Current with DPI Adjustment Triac ( phase cut) forward and revers phase, 0-10/1-10V, Potentiometer, PWM - 5 in 1 Universal Dimming. Universal input voltage 100-277V 50/60Hz. Strong combability, flicker free dimming. Good efficiency >83%. Power Factor 0.99 Cooling by free air convection. Full protection plastic housing IP20 rating for indoor installation. Input, output and dimming terminal blocks for easy installation. Protection: short circuit, over load and over temperature, recover automatically after fault condition is removed.

Wattage: 10W, 20W, 40W and 60W
Output Voltage: 3-65V depend a model and of a current
Input Voltage: 100-277V
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits

ECC-010-UD
10 3-42VDC 100-277V 50/60Hz single

ECC-020-UD
20 3-42VDC 100-277V 50/60Hz single

ECC-040-UD
40 3-65VDC 100-277V 50/60Hz single

ECC-060-UD
60 3-65VDC 100-277V 50/60Hz single
