ELCO Lighting EL49530DW 12W 4" 0-10V LED Inserts 3000K - White Finish

The Ply System 0-10V dimmable LED Inserts are engineered with energy-efficient LED technology and with a 120/277V 0-10V dimmable driver for a budget friendly 0-10V solution. Designed to be used for New Construction, Remodel with ELCO Ply System Housings or as a retrofit with existing housings.

FEATURES :

• 0-10V Dimmable

• 120/277V Driver

• Soft white lens provides smooth lumen distribution and eliminates LED pixelation

• Deep set LED trim reduces glare while providing even illumination

• 93+ CRI for extremely accurate color rendering

• CA Title 24, ETL listed, ENERGY STAR, JA8-2016-E

• Life span of 50,000 hours L70


SPECIFICATIONS :

• Wattage : 12W

• Lumens : 800 lm - 900 lm

• Voltage : 120/277V

• Color Temp. : 3000K - 4000K

• Dimmable : 0-10V

• CRI : 93+

• Wet Location : Listed

Optics: Frosted polycarbonate lens diffuses light evenly throughout while reducing glare with LED Array technology.

Construction: For use in IC and non-IC housings. Spun Aluminum for greater heat dissipation. High quality powder coat finish preventing rust and paint cracking.

Installation: Quick connect for use with ELCO 4" 0-10V Dedicated LED Housings ELJ444ICDXA, ELJ444ICDXAB, ELJ444ICDXA-EM5, EL49FICDXA, EL49FICDXA-B, EL490ICDXA, EL490ICDXA-B, EL490ICDXA-EM5, EL490RICDXA, EL492ICDXA, EL492ICDXA-B and EL492RICDXA.

Electrical: Driver connects to 120/277V power supply. High Efficiency driver with a power factor > 0.9. Start time of less than .75 seconds.

LED Technology: Extremely accurate color rendering with 93+ CRI. Lumen Maintenance of 50,000 hours L70 Life based on LM80 standardized test results. Superior Thermal Management by utilizing integral heat sink. Instant On to Full Brightness. No LED pixelation.

Dimmability: Works with 0-10V dimmers . Dims down to 10%. For full list of dimmers refer to the Dimmer Compatibility List. Industry leading dimming. Dims smoothly with no hot spots or flickering.

Listings: UL Listed for Wet Location. RoHS Compliant. ENERGY STAR® Certified. California Title 24 JA8-2016-E.

Warranty: ELCO Products are built to last with a 5-year Limited Warranty.

Labels and Listings:
cULus Listed for US and Canada
UL Listed for Damp Location.
Meets Title 24 high efficacy requirements.
ENERGY STAR® Certified.
