Elco Lighting EL331CT3W 9W 3" Square LED Baffle Insert Recessed Lighting Trim 3 CCT - White Finish

ELCO Lighting's inserts are engineered with energy-efficient LED technology that produces even illumination with an incredible 93+ CRI. Designed to be used for New Construction, Remodel, and Retrofit applications, these inserts are rated for a life of 50,000 hours, and meet the Title 24 and Energy Star requirements. Suitable for IC and Non-IC housings manufactured by ELCO or others.

FEATURES :

• Fits ELCO 3‚¬²‚¬² Dedicated LED Recessed Housings for New Construction and Remodel.

• Soft white lens provides smooth lumen distribution and eliminates LED pixelation.

• Deep set LED trim reduces glare while providing area illumination.

• Diecast construction provides lasting durability.

• CA Title 24, ENERGY STAR, JA8-2016-E.

• Lifespan of 50,000 hours L70.


SPECIFICATIONS :

• Wattage : 9W

• Lumens : 620 lm - 640 lm

• Voltage : 120V

• Color Temp. : 2700K - 3500K

• Dimmable : Triac/ELV

• Lamp Type : LED

• Beam Angle : 90°

• CRI : 93+

• Wet Location : Listed

Optics: Frosted polycarbonate lens diffuses light evenly throughout while reducing glare with LED Array technology.

Construction: For use in IC and non-IC housings. Diecast construction for lasting quality and greater heat

dissipation. High quality powder coat finish preventing rust and paint cracking.

Installation: Quick connect for use with ELCO housings EL390ICA, EL390RICA, EL39FICA.

Electrical: Driver connects to 120V power supply. High Efficiency driver with a power factor > 0.9.

LED Technology:
Extremely accurate color rendering with 93+ CRI.
Lumen Maintaince of 50,000 hours L70 life based on LM80 standardized test results.
Superior Thermal Management by utilizing integral heat sink.
Instant On to Full Brightness.
No LED pixelation.

Dimmability: Works with 120V Triac and ELV type dimmers . Dims down to 10%. For full list of dimmers refer to the Dimmer Compatibility List.

Warranty: ELCO Products are built to last with a 5-year Limited Warranty.

Labels and Listings:
UL Listed for Wet Location
RoHS Compliant
ENERGY STAR® Certified
California Title 24 JA8-2016-E
