Description
Eaton BQC230230 Thermal Magnetic Circuit Breaker
- Product Name: Eaton BR Thermal Magnetic Circuit Breaker
- Catalog Number: BQC230230
- UPC: 786676371896
-
Product Dimensions:
- Length/Depth: 3 in
- Height: 3 in
- Width: 2 in
- Weight: 0.9 lb
- Compliances: Federal Specifications Classification W-C375
- Certifications: UL 489
- Catalog Notes: All Type BD Duplex and BQ Quadplex circuit breakers are HACR application listed. 15 and 20 ampere single poles are switch duty rated.
Product Specifications:
- Type: Type BQC 1-Inch CTL Plug-On Circuit Breaker
- Special Features: Includes Rejection Tab Feature
- Amperage Rating: (2) Two-Pole 30A
- Voltage Rating: 120/240 V
- Trip Type: Common Breaker Trip
- Circuit Breaker Type: BQC
- Used With: Type BR Loadcenters
- Mounting Method: Plug-On
- Interrupt Rating: 10 kAIC
- Main Circuit Breaker: BQC
- Wire Size: #14-4 AWG Cu/Al
- Number of Poles: Four-Pole
