Westgate | Product Number: LRX-50-120W-MCTP
Westgate 120W Power and CCT-Adjustable LED Barn/Area Light
30-day returns Read terms & conditions
Top rated store Read 5-star reviews
Orders ship within 2 business days
Safe & secure checkout
Product details
Description
Technical Specs
- Die-cast ADC12 Aluminum Alloy, Outdoor Powder Coated
- 1-1/4" EMT Elbow Mounting Strap Included
- NEMA Twist-Lock Photocell Included
- Multi-CCT, Switch on bottom of fixture
- Dimming: 0-10V Dimming
- Lens: Polycarbonate Lens, High light transmittance PC, Anti-UV and Fire Resistant
- Aluminum LED Board: High conductive, waterproof, aging resistant, salt resistant
- Lumens Range: 7800-17000LM
- Wattage: 50W/80W/100W/120W
- Voltage: 120~277V AC 60Hz
- Efficacy: 130LPW
- Beam Angle: 90 x 110
- Power Factor: 0.90
- Operating Temp: -4F to 104F
- THD: 20%
- Color Rendering Index: CRI 70
- Color Temp: 3500K/4000K/5000K/5700K
- Lifespan: 70,000 hours
- 7-year warranty
- IP Rating: IP44, Wet Locations
Applications
- LED Dusk to dawn light with photocell ideal for general site lighting, yard/barn lighting, loading docks, doorway, pathway and parking areas.
Features
Download PDF File
Catalog Page
Specification
Installation Instructions
