ELCO Lighting ELST9930W Mini LED Step Light 2.5W 3000K 50lm 120V - White Finish

Mini LED Step Light

FEATURES :

Adaptive Diecast Aluminum faceplate design allows for
Vertical or Horizontal orientation.
Powder Coated Faceplate
Vertical or Horizontal Mounting
Integrated LED board and driver
Diffused lens behind faceplate
Wet Location listed for indoor use
IC Rated for direct contact with insulation
Mounts in a standard single gang box
Life span of 50,000 hours L70
Input Voltage: 120V

SPECIFICATION :

• Wattage 2.5W

• Lumens 50 lm

• Voltage 120V

• Color Temp. 3000K

• Lamp Type LED

• CRI 90+

Optics:
Frosted lens diffuses light and illuminates walkway.

Construction:
Diecast Faceplate with smooth powder coat finish. LED board and driver integrated in housing.
Security screws for mounting faceplate to box included.

Installation:
Easily installs into a standard single gang switch box.

Electrical:
Ambient operating temperature -23°F (-5°C) to 113°F (45°C).
120V ELST95: Driver input of 120V 50/60Hz connects directly to line voltage power.
12V ELST91: Input of 12V requires an external transformer.

LED Technology:
90+ CRI for extremely accurate color rendering.
Lumen Maintenance of 50,000 hours L70 Life.
LED Array.

Listings:
cETLus listed for Wet Location.
